Synthesis & Patterning

Glovebox System

MBRAUN Glovebox system integrated with solar simulator IV testing & high vacuum coating equipment

Synthesis Setup 1 Synthesis Setup 2

High-throughput synthesis platform #1: Spin-Bot housed inside an MBRAUN Glovebox

Spin-Bot

High-throughput synthesis platform #2: Liquid-handling robot

Patterning System – UV Maskless Lithography (ACA Master)

Characterizations

Multi-Channel Solar Cell Lifetime Test System with Environmental Chamber (Room BC716)

XRD – Rigaku SmartLab / SmartLab Advance / SE – 3kW (Room BC710)

AFM – BRUKER Scanning Electrochemical Microscopy System (Room FJ703)

SEM – Field Emission Scanning Electron Microscope (Tescan MIRA, Room BC710)

TEM – Field Emission Transmission Electron Microscope (JEOL JEM-2100F, Room CF002)

FTIR – Bruker Vertex-70 Fourier Transform Infrared Spectrometer (Room DE702a)

UV-Vis Spectrophotometer – SHIMADZU UV-3600i Plus (Room FJ704)

XPS – Thermo Fisher Scientific Nexsa (Room BC717)

WITec alpha300-apyron Raman Imaging System (Room BC718)

More tools can be found in University Research Facility Management System (URFMS)
